As332p-a/16di, 16do (NPN) , 6 Groups of 200K Ab Phase Input, 6 Axes of 200K Ab Phase Output, 128K Step Capacity, Built-in Ethernet Port, RS485X2, Micro SD Card,
Product description: As332p-a/16di, 16do (NPN) , 6 Groups of 200K Ab Phase Input, 6 Axes of 200K Ab Phase Output, 128K Step Capacity, Built-in Ethernet Port, RS485X2, Micro SD Card,
Programmable logic controller (PLC) is a control system using electronic operations. Its easy storing procedures, handy extending principles, functions of sequential/position control, timed counting and input/output control are widely applied to the field of industrial automation control.
Delta's DVP series programmable logic controllers offer high-speed, stable and highly reliable applications in all kinds of industrial automation machines. In addition to fast logic operation, bountiful instructions and multiple function cards, the cost-effective DVP-PLC also supports various communication protocols, connecting Delta's AC motor drive, servo, human machine interface and temperature controller through the industrial network in to a complete "Delta Solution" for all users ES2 series is a small PLC for basic sequential control. It is economical, highly efficient and functional. Applications: HVAC, molding injection machine, big storage management, packaging machine, precise textile machine, logistic system. Specifications: MPU points: 16 / 20 / 24 / 32 / 40 / 60 Program capacity: 16k steps Built-in with 3 COM ports: 1 RS-232 port and 2 RS-485 ports, all are able to operate independently (Master/Slave) Max. I/O points: 256 input points + 16 output points, or 256 output points + 16 input points DVP-EX2 MPU is built in with 12-bit 4AD/2DA and offers analog/temperature modules of 14-bit resolution. Built-in with 8 high-speed input points (2 points for 100kHz, 6 points for 10kHz) and supports U/D, U/D Dir, A/B counting modes New motion control instructions: Close loop control, alignment mark, shield, immediate variable speed, S-Curve acceleration/deceleration Application in emerging industry: Exclusive instructions and function blocks designed for PV solar tracker Handy instructions for frequency inverter: For controlling the forward running, reverse running, RUN and STOP of Delta@@s AC motor drives Password protection: Password for subroutine, user ID, restriction on trial times Highly efficient instruction efficient instruction execution
