DELTA

  • DOP-B107BV
  • DOP-B107BV
DOP-B107BVDOP-B107BV

DOP-B107BV

  • Product description: The Basic HMI B Type is easy to install and offers basic functions for general industrial applications. With an IP65 rating, it is suitable for harsh environments.Multiple size options: High-perform
  • INQUIRY

The Basic HMI B Type is easy to install and offers basic functions for general industrial applications. With an IP65 rating, it is suitable for harsh environments.

Product Introduction

Features & Benefits
  • Multiple size options: 4.3” /  7”
  • High-performance CPU: Cortex-A8
  • Highly integrated design: Built-in 2 serial communication ports (D-Sub x 1), USB, and more
  • Certification: CE / UL
Applications

Machinery and equipment in various sectors such as packaging, textiles, woodworking, rubber, and plastics

Specifications
   DOP-103BQ  DOP-107BV
Display 4.3" TFT 7" TFT
Resolution  (Pixels) 480 x 272 800 x 480
Color 16-bit
CPU  Cortex-A8 800 MHz
ROM  256 MB
RAM 256 MB
COM Port 2 Serial COM Ports
USB 1 Slave / 1 Host
Certification  CE / UL
Operating Temperature  0 ~ 50°C
Storage Temperature  -20 ~ 60°C


DOP-107BV

  Dimensions (W x H x D, mm) Mounting Dimensions (W x H, mm)
  DOP-103BQ 137 x 103 x 37.1 118.8 x 92.8
  DOP-107BV 215 x 161 x 35.5 196.9 x 142.9
